技術特點:
1、Chinese and English color touch screen display, intuitive and simpleoperation.中英文彩色觸摸屏顯示，操作直觀，簡單。
2、PLC computer control system, more stable operation, can adjust anyparameters without stopping the machinePLC電腦控制系統，運行更穩定，可不停機調整任何參數。馬、Can store 10 sets of packaging parameters, easy to replace the
packaging specifications.
可儲存十組參數，更換品種更準確。
4、Using servo motors for vacuum film pulling and suction for moreaccurate positioning.
采用伺服電機真空拉膜吸膜，定位跟準確。Using a temperature controller, the temperature difference can becontrolled within 2 °C.
獨立溫控系統，溫差控制在2℃C以內。
6、The horizontal and vertical sealing temperatures are independentlycontrolled, making it suitable for various packaging materials such ascomposite films and PE films.
橫、縱封溫度獨立控制，能良好的適用各種復合膜、PE膜等包裝材料。
技術參數：
| 機 型(TYPE) | RH-720 |
| 制袋長度(Bag length) | 100-500mm(L)250-400mm(w) |
| 制袋寬度(Bag width) | 15-35bag/min |
| 包裝速度(Packing speed) | 0.65mpa |
| 氣壓(Air consumption)耗氣量(Gas consumption) | 0.8m/min |
| 電源(Power) | 220V |
| 功率(Power) | 700W |
| 外型尺寸(Dimension) | (L)1600mmx(w)1530mmx(H)2110mm |
| 重量(Machine weight ) | 650kg |
